MultiCut 08
For single dwelling or extensions
The unique MultiCut cutting system ensures a maximum of operational safety at outstanding delivery characteristics. Fitted with a cutter plate made of hardened stainless steel and a three-bladed knife, it disintegrates coarse additions in the wastewater with more than 200,000 cutting processes per minute before they can get into the pump hydraulics. Solids which cannot be transported are rejected outside of the pump by the cutting rotor as the cutting system is located upstream from the pump hydraulics. Specifically arranged grooves on the cutter plate ensure additional safety as the cutting unit is permanently cleaned automatically during the delivery.
Key Information
| Type | Code No. | Ciruit | Voltage | Motor rating P1 | Motor rating P2 | Current | Motor protection | Plug | S3 | Motor housing |
|---|---|---|---|---|---|---|---|---|---|---|
|
MultiCut 08/2 ME
|
JP50342
|
Without level control
|
1/N/PE~230 V
|
1.37 kW
|
0.98 kW
|
6 A
|
In motor
|
Safety
|
10 %
|
Stainless steel
|
|
MultiCut 08/2 M
|
JP50344
|
Without level control
|
3/PE~400 V
|
1.65 kW
|
1.24 kW
|
2.8 A
|
In motor
|
CEE-16A
|
10 %
|
Stainless steel
|
|
MultiCut 08/2 M, Ex
|
JP50346
|
Without level control
|
3/PE~400 V
|
1.65 kW
|
1.24 kW
|
2.8 A
|
With control unit
|
Without
|
35 %
|
Grey cast iron
|
|
MultiCut 08/2 MES
|
JP50343
|
With built-in level control
|
1/N/PE~230 V
|
1.37 kW
|
0.98 kW
|
6 A
|
In motor
|
Safety
|
10 %
|
Stainless steel
|
|
MultiCut 08/2 MS
|
JP50345
|
With built-in level control
|
3/PE~400 V
|
1.65 kW
|
1.24 kW
|
2.8 A
|
In motor
|
CEE-16A
|
10 %
|
Stainless steel
|
Multicut 08 Data sheet
Multicut 08 Manual
Multicut 08-20 Spares
Multicut 08 Spares
Multicut 08 Brochure
Please allow a short time for the 3D image to load. You can then click on the image to rotate it.
Please allow a short time for the 3D image to load. You can then click on the image to rotate it.
We stock many Jung Pumpen spares at our warehouse in Aldermaston. Please call the office on 0118 9821 555 if you need help, or to place an order.
| Type | Code No. | Type | Code No. |
|---|---|---|---|
| Capacitor | JP46016 | 10x Scheibe / Shim ring 12x16x0,2 | JP48114 |
| Contactor | JP46056 | 10x Scheibe / Shim ring 12x30x0,1 | JP48082 |
| Microswitch 230 V | JP46351 | 10x Scheibe / Shim ring 12x30x0,2 | JP48083 |
| Microswitch 400 V | JP46352 | 10x Scheibe / Shim ring 12x30x0,3 | JP48084 |
| Top cover MS, MES | JP46018 | 10x O-Ring 10×2,5 | JP48088 |
| Top cover M, ME | JP46019 | 10x O-Ring 21×2 | JP50323 |
| Float | JP46022 | ||
| Switch shaft | JP46020 | ||
| Switch cartridge | JP46025 | ||
| Cable 230 V | JP42777 | ||
| Cable 400 V | JP42779 | ||
| Cable with A/NZ plug (230V) | JP47221 | ||
| Bearing set | JP46042 | ||
| Shim rings | JP46559 | ||
| Rotor Shaft 230 V | JP46551 | ||
| Rotor Shaft 400 V | JP46552 | ||
| Stator + housing 230 V | JP46029 | ||
| Stator + housing 400 V | JP46030 | ||
| Seal set | JP46041 | ||
| Impeller M | JP45467 | ||
| Impeller 60 Hz | JP46555 | ||
| Impeller ME | JP46556 | ||
| Pump casing | JP46553 | ||
| Oil screw | JP46046 | ||
| Mechanical seal | JP46043 | ||
| Cutter plate | JP50324 | ||
| Screw set | JP46560 | ||
| Cutter | JP50326 | ||
| Wear plate | JP46557 | ||
| Pulling device for cutting system |
JP50325 | ||
| Pump pedestal | JP44759 | ||
| 1l Oil | JP48236 |
Please download the Multicut spares list
